Bistable relay RPB-2PSM-UNI
Bistable relay RPB-2PSM-UNI
Bistable - impulse relays sequential with memory, 2 CO, universal control voltage 12...240 V AC/DC. Cooperation with momentary (bell) switches or control buttons.
Technical info
Connection diagrams bistable - impulse relays RPB-2PSM-UNI
| Output circuit - contact data |
||
| Number and type of contacts |
2 x 1 CO |
|
| Max. switching voltage |
300 V AC/ 300 V DC |
|
| Rated load |
AC1: 16 A / 250 V AC; DC1: 16 A / 24 V DC |
|
| Max. inrush current |
30 A |
|
| Input circuit |
||
| Rated voltage |
12...240 V AC/DC |
|
| Rated power consumption |
≤ 1,7 W |
|
| Control contact S |
||
| Load |
no |
|
| Min. voltage |
0,85 Un |
|
| Min. time of pulse duration |
≥ 55 ms |
|
| General data |
||
| Electrical life AC1 |
0,5 x 105 contact 1NO 16 A; 250 V AC |
|
| Mechanical life (cycles) |
107 |
|
| Ambient temperature - operating |
-20...+55 oC |
|
