Bistable relays RPB-1PM-UNI

Technical info

Connection diagrams bistable - impulse relay  RPB-1PM-UNI

Schemat 1PM UNI_ 1ZMI UNI



Output circuit - contact data

Number and type of contacts

1 CO

Max. switching voltage

300 V AC/ 300 V DC

Rated load

AC1: 16 A / 250 V AC;  DC1: 16 A / 24 V DC

Max. inrush current

30 A

Input circuit

Rated voltage

12...240 V AC/DC

Rated power consumption

≤ 1,7 W

Control contact S

Load

ΣI < 5 mA

Min. voltage

0,85 Un

Min. time of pulse duration

≥ 55 ms

General data

Electrical lifei AC1

0,5 x 105  contact 1NO 16 A; 250 V AC

Mechanical life (cycles)

107

Ambient temperature - operating

-20...+55 o

Download the RPB user manual
